- Strip led 220V
Strip LED COB 5M 14W/m 220V IP65 Dimmable Light color tone-3000°K WARM LIGHTAvailable in different variants$127.99 $89.60- On sale!
- -30%
Lampo Strip LED 5050 60led/m 24V 14.4W/mt Reel 5M 72W Light color tone-3000°K WARM LIGHT, Version-IP20 For IndoorAvailable in different variants$72.87 $43.72- On sale!
- -40%
Alcapower Strip LED Snake Flex profile 11W/m 220V IP65 Dimmable Light color tone-3000°K WARM LIGHT, Lunghezza-5 metersAvailable in different variants$219.74 $153.82- On sale!
- -30%
- add remove
- add remove
- add remove
- Strip led 220V Strip LED COB 5M 14W/m 220V IP65 Dimmable Light color tone-3000°K WARM LIGHTAvailable in different variants$127.99 $89.60
- On sale!
- -30%
Lampo Strip LED 5050 60led/m 24V 14.4W/mt Reel 5M 72W Light color tone-3000°K WARM LIGHT, Version-IP20 For IndoorAvailable in different variants$72.87 $43.72- On sale!
- -40%
Alcapower Strip LED Snake Flex profile 11W/m 220V IP65 Dimmable Light color tone-3000°K WARM LIGHT, Lunghezza-5 metersAvailable in different variants$219.74 $153.82- On sale!
- -30%
- add remove
Reference: A40PLKE1090B
PLKE 109 phase cut Tric dimmable power supply unit with 350mA constant output current and 9.5W maximum power suitable for TRIAC, IGBT, MOSFET dimmers.
Reference: 122360
Electronic power supply adjustable in direct current from 60mA to 360mA. Multi-power power supply equipped with dip-switch with the selection of the output current. IP20 independent power supply, for indoor use. Rated voltage 110-127V or 220-240V. Dimensions 115x34x19 mm
Reference: DRPFMDALI26700
Ledvance electronic power supply DR DALI-PFM-26/220-240/700 multipower in direct current from 150mA to 700mA adjustable with DALI system (DALI2), maximum power consumption 26.3W.
Reference: 125504
Electronic power supply adjustable in constant current from 350mA to 1.2A. Multipower supply equipped with dip-switch with the selection of the output current. IP20 independent power supply, for indoor use. Possibility to adjust the light intensity through the DALI, ADIM or Push system. Nominal voltage 110-127V or 220-240V. Dimensions 124x79x22 mm
Reference: LPC-20-700
LPC-20-700 power supply, 21W electronic driver with 700mA constant current output, and variable direct current DC 9-30 volts.
Reference: APC-35-350
Constant current power supply for LED 35W max 350mA
Reference: 99186
iLed for Linea Light Aqualed power supply unit for 6-12 constant current modules for LEDs of 630mA 24W MAX. Nominal output voltage DC (under load) 17-40V.
Reference: 99179
iLed for Linea Light Aqualed power supply unit for 3-6 constant current modules for LEDs of 630mA 12W MAX. Nominal output voltage DC (under load) 9-20V.
Reference: APC-16-350
Mean Well LED power supply model APC-16-350, with power of 16W 0.5A at 350mA constant current. Degree of protection IP42 also for outdoor use.
Reference: 127571
Electronic 220-240V power supply of small dimensions adjustable in direct current with DIP-SWITCH for the selection of the direct current in output.Output current from 125mA to 500mA.
Reference: DRPFMDALI601A4
Ledvance electronic power supply DR DALI-PFM-60 / 220-240 / 1A4 multipower in direct current from 700mA to 1.40A adjustable with DALI system (DALI2).
Reference: LCM-25DA2
Constant current multi-power power supply, output from 350mA to 1050mA. Dimmable with DALI 2 system. Maximum output power 25.2W.
Constant current power supplies
Diffusione luce offers for sale a complete range of constant current electronic power supplies for LED applications. To choose the right constant current power supply it is necessary to carry out this calculation: current absorbed by the LED spotlight x working voltage of the spotlight. Example: 0.350 A x 3.4 volts = 1.2 W (power absorbed by the spotlight). In this case, you must choose a power supply with an output power starting from 1.2W and a current of 0.350 A. Do not install power supplies with a minimum output power higher than the nominal power absorbed by the installed spotlight, for example: 1.2W and 350mA spotlight with power supply starting from 4w and 350mA -> wrong and broken LED diode. Different matter when LED spotlights are installed in series, in this case to calculate the power of the power supply it is necessary to add the power of the spotlights, example: 10 products of 1.2w and 350 mA = 12w 350mA -> necessary power supply with nominal power minimum 12w 350mA. Meanwell electronic ballasts with IP65/IP67 protection ratings are also available for outdoor applications.
