Constant current power supplies

Reference: KVG-24060-DH

Generico

Available in different variants

LED power supply in constant voltage 60W max at 12Vdc dimmable (5 in 1) with Phase dimming: work with Forward phase, MLV and Reverse phase, ELV, TRIAC dimmers. 0-10V dimming: 0-10V/1-10V/Potentiometer/10V PWM 4 in 1. Dimming range: 0-100%. Available at 200-240V and 100-277V. Dimensions: 178x61x24mm.

Price $64.11
Shipped in 7-21 days

Reference: KVG-12060-DH

Generico

Available in different variants

LED power supply in constant voltage 60W max at 12Vdc dimmable (5 in 1) with Phase dimming: work with Forward phase, MLV and Reverse phase, ELV, TRIAC dimmers. 0-10V dimming: 0-10V/1-10V/Potentiometer/10V PWM 4 in 1. Dimming range: 0-100%. Available at 200-240V and 100-277V. Dimensions: 178x61x24mm.

Price $64.11
Shipped in 7-21 days

Reference: KVG-48060-DH

Generico

Available in different variants

LED power supply in constant voltage 60W max at 48Vdc dimmable (5 in 1) with Phase dimming: work with Forward phase, MLV and Reverse phase, ELV, TRIAC dimmers. 0-10V dimming: 0-10V/1-10V/Potentiometer/10V PWM 4 in 1. Dimming range: 0-100%. Available at 200-240V and 100-277V. Dimensions: 178x61x24mm.

Price $64.11
Shipped in 7-21 days

Reference: 127572

TCI

Electronic driver adjustable in direct current with DIP-SWITCH. Multipower supply equipped with dip-switch for the selection of output current. IP20 driver, for indoor use. Voltage 220-240V. Dimensions: 146.5x43x22 mm. Constant current output from 125mA to 500mA. Dimensions: 146,5x43,5x22 mm.

Price $43.09 Regular price $53.86
Shipped in 1-2 days

Reference: KIG-060-DH

Generico

Available in different variants

Constant current LED driver, 60W multi-current at 2100mA max, dimmable Triac ELV, 0-10V, 1-10V, potentiometer, 10V PWM. Available at 200-240V and 100-277V. Dimensions: 171.5x54x20mm.

Price $44.88
Shipped in 1-2 days

Reference: KIG-040-DH

Generico

Available in different variants

Constant current LED driver, 40W multi-current at 1400mA max, dimmable Triac ELV, 0-10V, 1-10V, potentiometer, 10V PWM. Available at 200-240V and 100-277V. Dimensions: 171.5x54x20mm.

Price $37.19
Shipped in 1-2 days
Sale Constant current power supplies

Constant current power supplies

Diffusione luce offers for sale a complete range of constant current electronic power supplies for LED applications. To choose the right constant current power supply it is necessary to carry out this calculation: current absorbed by the LED spotlight x working voltage of the spotlight. Example: 0.350 A x 3.4 volts = 1.2 W (power absorbed by the spotlight). In this case, you must choose a power supply with an output power starting from 1.2W and a current of 0.350 A. Do not install power supplies with a minimum output power higher than the nominal power absorbed by the installed spotlight, for example: 1.2W and 350mA spotlight with power supply starting from 4w and 350mA -> wrong and broken LED diode. Different matter when LED spotlights are installed in series, in this case to calculate the power of the power supply it is necessary to add the power of the spotlights, example: 10 products of 1.2w and 350 mA = 12w 350mA -> necessary power supply with nominal power minimum 12w 350mA. Meanwell electronic ballasts with IP65/IP67 protection ratings are also available for outdoor applications.
