QLT Dimmer LED Driver Dali Dimmable 1-10V 144-288W for Strip LED
  • QLT Dimmer LED Driver Dali Dimmable 1-10V 144-288W for Strip LED
  • Dimmer QLT LED Driver Dali Dimmable 1-10V 144-288W for Strip LED
  • Dimmer QLT LED Driver Dali Dimmable 1-10V 144-288W for Strip LED

QLT Dimmer LED Driver Dali Dimmable 1-10V 144-288W for Strip LED

kr468.81
24 / 48 hours

More buy more save

For 10 products spend per unit

QLT LED DALI Dimmer A40DALI1000B, dimmable driver 144-288W with 12-24V DC input and DALI, 1-10V or push button control for LED strips.

Read more ... arrow_drop_down
6 Items
local_shipping
Shipped in 1-2 daysinfo

Quantity

Product accessories
Description

The QLT LED DALI Dimmer A40DALI1000B is a professional dimmable LED driver manufactured by QLT, designed to control LED strips and modules via DALI protocol or 1-10V signal. Built in polycarbonate with IP20 protection rating and Insulation Class II, its compact footprint — 138 × 40 × 28.5 mm — makes it straightforward to integrate into virtually any installation.

This DALI dimmer for LED strips accepts an input voltage of 12 to 24V DC and handles resistive loads up to 12A, delivering a 300 Hz PWM output: at 12V the maximum power output is 144W, rising to 288W at 24V. The adjustable output from 0 to 24V DC enables precise and continuous brightness management of connected LED strips. The control mode — DALI with push button or 1-10V with potentiometer — is selected via jumper, ensuring installation flexibility across a wide range of configurations, from residential smart lighting systems to professional environments.

For dimensions, technical specifications and further product information, please refer to the attached PDFs.

QLT
Guaranteed Original Product
6 Items

Data sheet

Barcode
8058774344846
Reference
A40DALI1000B
Input voltage
12-24 V DC
Output voltage
0-24V/DC
Depth in mm
28.5
Width in mm
40
Length in mm
138
Degree of protection
IP20
Material
Polycarbonate
Light source
LED
Adjustable power
with DALI system
Current carrying capacity
12A
Power output in watts
144-288
Insulation class
Insulation class II
output number
1
Download
picture_as_pdf Scheda tecnica picture_as_pdf Download 1
