Light Shadow Dots Ø30 - High brightness compact recessed LED downlight for indoor environments.
Read more ...It can be installed in Trim or No Trim version (with or without frame), and in both cases the installation formworks must be ordered separately. Possibility of installation in sets of 1, 2, 4 spotlights.
Light Shadow Dots is a revolutionary family of downlights, developed to control glare in countless applications. The exclusive patented optical system has been declined in different beam angles made ad hoc for specific applications such as offices, retail and domestic environments. Dots takes glare control to an extreme level, where optical efficiency values are extremely high thanks to the use of latest generation technologies.
Light Shadow Dots has a diameter of 30mm and an extremely reduced recess depth, which are combined with a complex optical system that provides extreme shielding of the source, thanks to the inverted shape of the cut-off cones that characterize it. It can be installed in the TRIM (with frame) and NO TRIM (without frame) versions; The frameless option allows you to install the luminaire in a plasterboard ceiling, integrating it perfectly flush with the ceiling. With this option it is also possible to create a modular arrangement in line (2 or 4 spotlights) at two different distances between one spotlight and another. Conversely, the framed option is for single installations only and still requires an installation formwork to be ordered separately.
Concept - LED light module, low glare, to be inserted in the recessed frames (not included). Installation via bayonet system with interchangeable spotlights. Available in single light versions and groups of two or four lights. Driver not included, the driver must be connected directly to the recessed frames. It is available in four different optics (Spot, Medium, Flood, Wide Flood). To solve the decorative problems of certain environments, a range of colors has been created with different interior finishes: white, steel, bronze, copper and black. The black finish provides the highest level of visual comfort, minimizing glare and direct visibility of the LED source.
Via remote driver NOT included, it is possible to adjust it in 0-10V, Dali, Dali 2, Main dimming and Casambi. To manage with the Casambi system (max 200 devices) it is necessary to download the Flos Control app powered by Casambi (available in the Apple Store and Google Play) for mobile devices.
Mandatory accessories are NOT included, but must be ordered separately.
Dimensions
NOTE
Available ONLY ON REQUEST the version with light temperature 2700K.
Reference: 151403
IP20 multipower power supply equipped with dip-switch with the selection of the output current from 250mA to 700mA. Possibility to adjust the light intensity through the DALI system.
Reference: 122200
LED multipower direct current electronic ballast with DIP SWITCH from 350 to 900mA in constant current, from 10 to 24V in constant voltage.
Reference: 127484N
Electronic driver with DIP-SWITCH in direct current: (13W 300mA) (15W 350mA) (18W 400mA) (20W 450mA) (22W 500mA) (24W 550mA) (27W 600mA) (29W 650mA) (31W 700 mA) (32W 750 mA) (33W 800mA) (35W 850mA) (38W 900mA) (40W 950mA) (42W 1000mA) (42W 1050mA). Rated input voltage 220-240V.
Reference: 127413
Electronic power supply adjustable in constant current from 350mA to 1.05A. Multipower supply equipped with dip-switch with the selection of the output current. IP20 independent power supply, for indoor use. Possibility to adjust the light intensity through the DALI, 0-10V, 1-10V or Push system. Nominal voltage 110-127V or 220-240V. Dimensions...
Reference: LCM-25DA2
Constant current multi-power power supply, output from 350mA to 1050mA. Dimmable with DALI 2 system. Maximum output power 25.2W.
Reference: DRPFMDALI601A4
Ledvance electronic power supply DR DALI-PFM-60 / 220-240 / 1A4 multipower in direct current from 700mA to 1.40A adjustable with DALI system (DALI2).
Reference: 08.0661.14
TRIM installation frame for Light Shadow DOTS spotlights by Flos Architectural.
Reference: 08.0580.00
NO TRIM installation frame for Light Shadow DOTS by Flos spotlights. Different versions available for single or series installations.
Reference: 127120
Electronic power supply adjustable in direct current. 36W max DC power supply 900mA output. IP20 independent power supply, for indoor use. Nominal voltage 220-240V. Dimensions: 146.5x43x22 mm. Flos code: RF27370
