TCI Wireless signal converter MINI BLL-PWM/1 10V Push

Features: Interface which can convert a WIRELESS BLL signal into a PWM signals(1) or 0/1...10 V signal. By way of the 4 PWM outputs up to 20 LED drivers with SYNC port can be connected by means of a synchronization cable supplied separately(1). Class II protection against electric shock for direct or indirect contact. The converter can be powered directly from the mains (100 ÷ 240 VAC) or by a 12 VDC voltage. By means of the auxiliary output a 12 VDC load can be powered up to 2 W.

Protections:

 - against input over voltages from mains;

 - against short circuit and open circuit;

 - thermal protection = automatic resetting type;

 - Non-IC; minimum clearance distance from top and lateral

 sides to normally flammable building element or building

 insulation = 5 mm.

Minimum clearance distance from separate lamp or light source container = 5 mm

Operation Mode:Light regulation 0/1 - 100 % by means of PUSH L / LV function and APP or compatible devices for BLL integrated WIRELESS module.

Features of remote control dimming by APP:

- can turn on and off;

- independent regulation of 4 channels (RGB / RGBW / SINGLE CHANNEL /  2 CHANNELS);

- light show play.

Open collector” type PWM output. (1) Compatible ONLY with FULL PWM products. 0/1-10 V port Imax. 10mA, same function of PWM1 port.

Light regulation 0/1 - 100 % by means of PUSH L / LV function:

- a short push to turn ON and OFF;

- a longer push from ON state to enable colour selection mode;

- a longer push from OFF state to enable colours sequence mode;

- a longer push to increase or decrease light intensity;

- colour memory at mains restore.

PUSH L: High Voltage Push connected to the mains (normally open). PUSH LV: Low Voltage Push, no connection to the main (normally open). Maximum length of the cable, from push button to last driver, must be max. 15 m / 49 ft. In case of applications where the cable is longer than 15 m / 49 ft, keep this separate from the 240 V mains cable. ATTENTION: only use normally open push buttons with no incorporated warning light.

For more information, see the attached PDF
