TCI STM 6W 500mA DC Direct Current Electronic Drivers

The TCI STM 6W 500mA electronic driver is a professional direct current LED driver designed for built-in use in design lighting fixtures. Its universal input voltage of 100-240V ensures full compatibility with the main electrical standards worldwide: EU, Australia, USA, UK and Japan.

Thanks to its ultra-compact dimensions (50 x 40 x 22 mm) and PVC housing, this TCI driver integrates seamlessly into professional luminaires, backed by a 10-year manufacturer's warranty for long-term reliability.

Key technical features

The driver operates in constant current mode with an adjustable output between 125 and 500mA and a maximum output power of 6W, with output voltage up to 12.6V MAX. Current regulation is maintained within -8% / +5%, including temperature variations. Input and output terminal blocks are located on the same side, with a single terminal on both primary and secondary circuits, supporting wire cross-sections up to 2.5 mm² / AWG13. The protection rating is IP20 and insulation class II makes it suitable for class I and II lighting equipment.

Safety and protections

The TCI STM driver features built-in thermal protection and short-circuit protection, protection against mains voltage spikes, and overload protection, ensuring the highest safety standards during installation. The driver can be secured using slots for screws.

Applications

Ideal for powering LED modules and LED strips in residential and contract installations, the TCI STM 6W is the compact solution for integrating a reliable driver into design lighting systems.
