QLT Multicurrent LED power supply 250-700mA 42W max 84V 1-10V
    • QLT Multicurrent LED power supply 250-700mA 42W max 84V 1-10V
    • QLT Multicurrent LED power supply 250-700mA 42W max 84V 1-10V

    QLT Multicurrent LED power supply 250-700mA 42W max 84V 1-10V Push Dimmable

    Brand :
    SAR233.90
    The product can be ordered

    More buy more save

    For 5 products spend per unit
    For 10 products spend per unit
    For 20 products spend per unit
    Multi-current dimmable electronic power supply from 250mA to 700mA with DIP-SWITCH. Multi-power power supply equipped with dip-switch with the selection of the constant output current.
    Read more ...
    local_shipping Shipping time:
    Shipped in 7-21 working days
    cancel
    Availability on order
    call_made Click here for availability information

    Quantity

    Description

    Multi-power supply equipped with dip-switch for selecting the output current.

    0-10V / PUSH dimmable

    IP40 independent power supply, for indoor use.

    Protected in class II - SELV

    Auxiliary output min 3V max 84.

    Current regulated ± 5% including temperature variations.

    Adjustment memory even in the absence of mains

    Constant current output adjustable from 250 to 700mA

    Power supply: 200V - 240V / AC. Stabilized output

    Protections:

    - self-restoring against overheating

    - against the open circuit

    - against short-circuits on the secondary

    - Dimensioni 68x103x30 mm

    Selection of constant output current via dip-switch - Variants:

    24W 3 ... 84V 250mA cost

    29W 3 ... 84V 300mA cost.

    33W 3 ... 84V 350mA cost.

    38W 3 ... 84V 400mA cost.

    42W 3 ... 84V 450mA cost.

    47W 3 ... 84V 500mA cost.

    47W 3 ... 76V 550mA cost.

    47W 3 ... 70V 600 mA cost.

    47W 3 ... 64V 650mA cost.

    48W 3 ... 60V 700mA cost.

    QLT
    cancel
    Availability on order

    Data sheet :

    Reference
    A40PUL042BEB
    Input voltage
    100-240 V
    Depth in mm
    30
    Width in mm
    68
    Length in mm
    103
    Degree of protection
    IP40
    Adjustable power
    Dimmable
    Constant current output
    250~700mA
    Power output in watts
    42 w
    Insulation class
    Insulation class II
    Compatible voltage
    EU-AUD-USA-UK-JAP
    Download :

    attach_file Download
