Qlt INTRGB4 Interface 12-24V Multi-control RGBW and RGB Control unit with 4 channels
A40INTRGB40B
$63.41
24 / 48 hours
More buy more save :
If you buy
5
products the price is
If you buy
10
products the price is
If you buy
20
products the price is
Dimmable 4-channel RGBW and 3-channel RGB 12V or 24Volt (150/300W) control unit interface with DMX or DALI input, PUSH with self-test function and signaling LED. With DIP-SWITCH for control selection.
Description
Tech specs pdf
Product Information:
Interface for RGBW 4-channel and RGB 3-channel
. Control Interface - IP40 - Insulation class II
. Configuration by 3 or 4 output channels for RGB and RGBW power leds
. Constant voltage operation. Output 4 x 12/24V PWM o 3 x 12/24V PWM
. Push-Button input: on, off and colour regulation by one or more push-buttons
. DMX and DALI inputs with self-test function and LED signal
. Regulation curve: linear or exponential
. DMX Resistor settable by dip switches
. Possible parallel connection up to 10 x interfaces
Product Details
100% original product by :
1 Item
Data sheet
- Barcode:
- 8056585229550
- Reference
- A40INTRGB40B
- Input voltage
- 100-240 V
- Output voltage
- 12 / 24V DC
- Depth in mm
- 35
- Width in mm
- 76
- Length in mm
- 207
- Degree of protection
- IP20
- Material
- Pvc
- Light source
- LED
- Adjustable power
- Dimmable
- Change colors
- RGBW(RED-GREEN-BLUE-WHITE)
- Insulation class
- Insulation class II
- output number
- 4
