• On sale!
Meanwell Power Supply LPV-150-12 150W 12V 10A IP67 LED Constant
  • Meanwell Power Supply LPV-150-12 150W 12V 10A IP67 LED Constant
Meanwell Power Supply LPV-150-12 150W 12V 10A IP67 LED Constant

Meanwell Power Supply LPV-150-12 150W 12V 10A IP67 LED Constant Voltage Driver

LPV-150-12

Trustpilot
$37.83
Payment in installments with Scalapay
24 / 48 hours

More buy more save :

If you buy 5 products the price is
If you buy 10 products the price is
If you buy 15 products the price is
  • Max. output 150 W
  • Output description 12  0-10A
  • Power supply type  AC/DC power supply
  • Enclosure type  Enclosed Type
  • RoHS  Compliant
  • Suitable for medical  No
  • Dimmable  No
Quantity
Shipped in 1/2 days
29 Items

You can pay in installments with PAYPAL OR SCALAPAY
Description
Tech specs pdf
datasheet

Datasheet_lpv150
Product Information:

150W Waterproof (IP67) SMPSU External switch mode epoxy encapsulated IP67 rated power supplies High efficiency, long life and high reliability Designed for indoor or outdoor installations Suitable for LED lighting and moving sign applications Withstands 300Vac surge input for 5 seconds 100% full load burn-in test Fully regulated output Short circuit, over-current, over-voltage pro tection 600mm un-terminated, 2-core 18AWG input lead UL1310 Class 2 power unit, pass LPS EMC compliance to EN 55022 Class B Harmonic current compliance to EN 61000-3-2,-3 Stk nos 660-0252, 660-0255, 660-0259, 660-0268 are constant voltage power supplies Stk no 660-0261 is a constant current power supply

  • Max. output 150 W
  • Output description 12  0-10A
  • Power supply type  AC/DC power supply
  • Enclosure type  Enclosed Type
  • RoHS  Compliant
  • Suitable for medical  No
  • Dimmable  No

150W Waterproof (IP67) SMPSU External switch mode epoxy encapsulated IP67 rated power supplies High efficiency, long life and high reliability Designed for indoor or outdoor installations Suitable for LED lighting and moving sign applications Withstands 300Vac surge input for 5 seconds 100% full load burn-in test Fully regulated output Short circuit, over-current, over-voltage pro tection 600mm un-terminated, 2-core 18AWG input lead UL1310 Class 2 power unit, pass LPS EMC compliance to EN 55022 Class B Harmonic current compliance to EN 61000-3-2,-3 Stk nos 660-0252, 660-0255, 660-0259, 660-0268 are constant voltage power supplies Stk no 660-0261 is a constant current power supply

Product Details
29 Items

Data sheet

Barcode:
8058774341708
Reference
LPV-150-12
Input voltage
100-240 V
Output voltage
12 VOLT DC
Depth in mm
37
Width in mm
63
Length in mm
191
Degree of protection
IP67
Material
Polycarbonate
Current carrying capacity
10A
Power output in watts
150 w
Insulation class
Insulation class II
Efficiency %
88
USA JAP compatible
Compatible
