iGuzzini Pixel Led plus 196mm dimmable recessed LED downlight

The iGuzzini Pixel Plus 196mm is a dimmable recessed LED downlight with pull-out and adjustable body, manufactured by iGuzzini for installation in false ceilings. The structure is crafted in die-cast aluminium, with steel rotation hinges and a rotation ring featuring a protective carter in high-resistance thermoplastic material, ensuring durability and precise aiming. The orientable body offers outstanding pointing freedom: 40° inward, 65° outward and 355° axial rotation, making it an exceptional choice for accentuating architectural features, artworks and refined surfaces.

Thanks to its technical and aesthetic versatility, the Pixel Plus 196mm is perfectly suited for living room and office environments, as well as high-end commercial spaces. The integrated LED source of 31-32W delivers a luminous flux of up to 5210 lm at 3000K and 5190 lm at 4000K, with a CRI80 colour rendering index and an average lifespan of 50,000 hours. The passive thermal dispersion system protects and extends the LED component's service life. The high-efficiency reflector in superpure aluminium is available in three beam angles — 18°, 36° and 48° — to suit different lighting requirements. Dimming is managed via a DALI system, with the driver included and connected to the luminaire. A transparent tempered safety glass completes the build quality. The installation hole is Ø196mm, with steel wire spring fixing for ceiling thicknesses from 1 to 25 mm, and an input voltage of 100-240V.
