Eaglerise LED Power Supply 42W 150-1050mA DALI 0-10V PUSH Dimmable

£35.27
24 / 48 hours
Electronic power supply adjustable in constant current from 150mA to 1.05A. Mini driver Power supply, for indoor. Possibility to adjust the light intensity via DALI 2, 0-10V, 1-10V, Push system. Voltage 110-220V. (UL certificated)
Read more ... arrow_drop_down
4 Items
local_shipping
Shipped in 1-2 daysinfo

Quantity

Description
  • For luminaries of protection Class II，SELV，
  • Built-in/Independent（With side caps）
  • Input Voltage： 100-240VAC、176-280VDC
  • Protections：SCP/OLP/OVP/OTP
  • Power Factor：＞0.95
  • Efficiency：89%@full load,230VAC; 87%@Full
  • load,120VAC
  • Support DALI-2,Push Dimming,0-10V
  • Suitable for emergency lighting acc. to EN 50172
  • EOFi=15%
  • DALI maintainace(Part 251,252,253)
  • 5 years warranty
  • Applications
  • LED panel、LED down light
  • LED spot light

FLX-42-1050 DALI-2 0-10 LN PRO is a 42W constant current LED driver with 150 to 1050mA output current and a forward voltage range from 2.5 to 49Vdc. The output current is adjustable by NFC via APP. With it’ s dimensions from 97 x 43 x 30 mm. It is easy to integrate in LED Panel and down light products. To ensure trouble-free operation, protection is provided against output short circuit and over Load.

Power output based on constant current:

39.2W 2.5...49V 150-800 mA cost

41.8W 2.5...44V 801-950 mA cost.

42W 2.5...40V 951-1050 mA cost.

Generico
Guaranteed Original Product
4 Items

Data sheet

Barcode
8010703373532
Reference
FLX-42-1050
Input voltage
100-240 V
Depth in mm
30
Width in mm
34
Length in mm
97
Degree of protection
IP20
Adjustable power
Dimmable
Constant current output
150~1050 mA
Power output in watts
42 w
Insulation class
Insulation class II
Compatible voltage
EU-AUD-USA-UK-JAP
