Power supply QLT MPL3 4.2 W 12V 350mA for 2-3 LED modules

$ 13.38

A40MPL1031WN
8050539320065
QLT QUALITRON
New product
  • Indipendent driver - IP20 - Isolation's Class
  • Output in constant current 350mA, +/-10%
  • Self-resetting protection against overtemperatures, against open circuit and against output short circuits
  • Input voltage: 100-265V/AC
  • Steady output max 12V
  • Dimension: 51x32x18

Immediate shipment
2 Products in wharehouse

Availability information

Calculate shipping cost
Download :

Data_Sheet_MPL3

Download (593.55k)
Features :
In short :
  • Indipendent driver - IP20 - Isolation's Class
  • Output in constant current 350mA, +/-10%
  • Self-resetting protection against overtemperatures, against open circuit and against output short circuits
  • Input voltage: 100-265V/AC
  • Steady output max 12V
  • Dimension: 51x32x18
Description :

LED Drivers - Installation instructions


The drivers working in constant current must be used only with High Brightness LEDs that have the same current indicated on the driver itself. The max. number of LEDs that can be connected to the driver depends only on the kind of LEDs used. The red, green and yellow LEDs must be connected in the max. number indicated on the driver, as concern the white and blue LEDs connect always a piece less than indicated on the driver. Connect always the LEDs in series mode. Always pay attention to the polarity of the secondary cable. Put the system far from heat sources and in well aereted places. Thermical protection: if the temperature usually exceeds the limit values, the driver switches off and after a few seconds it switches on again. Avoid short circuit on the secondary side and give tension only after all LEDs have been connected. Lock the terminals carefully but do not tight by hand the terminal screw with excessive power or use electric screw-drivers with adjustable torque level. LEDs connection: always use a 0,5 ... 1,5 mm cable for a maximum length of 10 m Input wiring: use a H03VVH2F 2x0,75 input cable


Assistance :

Need help ?

Contact us now
Frequently asked
Shipping and price

About availability :

-> PRODUCT WITH QUANTITIES INDICATED -> Products are available in our warehouse and are ready for delivery.

-> NO LONGER IN STOCK -> Product is in out of production or no longer available from the supplier .

-> AVAILABLE ON ORDERING -> The products will be ordered from the supplier and if not indicated the waiting times vary from 5 to 15 days

Can't find your answers or information? For international customers there is an available phone number for your questions: +390541657672 , phone operating from 8.30am - 6.30pm monday - friday.

x

Input voltage100-240 V
Depth in mm18
Width in mm32
Length in mm51
Degree of protectionIP20
MaterialPolycarbonate
Light sourceLED
Constant current output350 mA
Power output in watts4.2
Insulation class Insulation class II
Maximum output voltage12V
USA JAP compatibleCompatible
