iGuzzini BA73 Linealuce 18W LED RGB DALI recessed spotlight
  • iGuzzini BA73 Linealuce 18W LED RGB DALI recessed spotlight
  • iGuzzini BA73 Linealuce 18W LED RGB DALI recessed spotlight
  • iGuzzini BA73 Linealuce 18W LED RGB DALI recessed spotlight
  • iGuzzini BA73 Linealuce 18W LED RGB DALI recessed spotlight
  • iGuzzini BA73 Linealuce 18W LED RGB DALI recessed spotlight
iGuzzini BA73 Linealuce 18W LED RGB DALI recessed spotlight
iGuzzini BA73 Linealuce 18W LED RGB DALI recessed spotlight iGuzzini BA73 Linealuce 18W LED RGB DALI recessed spotlight iGuzzini BA73 Linealuce 18W LED RGB DALI recessed spotlight iGuzzini BA73 Linealuce 18W LED RGB DALI recessed spotlight iGuzzini BA73 Linealuce 18W LED RGB DALI recessed spotlight

iGuzzini BA73 Linealuce 18W LED RGB DALI recessed spotlight waterproof IP67

3.BA73.715.0

instead of $1,170.68
$514.84 Save 56%

BLACK FRIDAY PRICE

Payment in installments with Scalapay
24 / 48 hours

More buy more save :

If you buy 5 products the price is
If you buy 10 products the price is
Luminaire with direct wall-washer emission designed for use with LED sources.
Quantity
Shipped in 1/2 days
2 Items

You can pay in installments with PAYPAL OR SCALAPAY
Description
Tech specs pdf
Product Information:

Luminaire with direct wall-washer emission designed for use with LED sources. RGB with multicolour 21Wmax 15 RGB (Red, Green and Blue) LEDs circuit, optic with plastic lenses, Flood version. Complete with lamp and Dali 48 - 56Vdc control board. Electronic ballast to be ordered separately. Extruded aluminium body subjected to phosphochromatisation treatment, double primer, passivation at 120° C, die­cast aluminium end caps with 50/60 Shore A silicone gaskets subjected to post­cooling treatment at 200°C C. Acrylic liquid paint finish with high resistance to atmospheric agents and UV rays; baking at 150°C. The optical assembly is closed with sodium-calcium tempered transparent clear semi-acid finished glass with antislip properties (in compliance with R12 class according to DIN 51130), 4mm thickness, fixed with silicone. Alluminium outer casing for installation with technopolymer caps to be ordered separately Ready for through wiring by means of four PG11 nickel­plated brass cable clamps suitable for 6.5 - 11mm cables contained in two thermoplastic boxs fixed to the optical assembly. All external screws are made of stainless steel A2.

  • Led lamp recessed
  • RGB change color system
  • DALI control system not included
  • Anticorrosive surface treatment
  • Power supply not included
product accessories
Luminaire with direct wall-washer emission designed for use with LED sources.

Luminaire with direct wall-washer emission designed for use with LED sources. RGB with multicolour 21Wmax 15 RGB (Red, Green and Blue) LEDs circuit, optic with plastic lenses, Flood version. Complete with lamp and Dali 48 - 56Vdc control board. Electronic ballast to be ordered separately. Extruded aluminium body subjected to phosphochromatisation treatment, double primer, passivation at 120° C, die­cast aluminium end caps with 50/60 Shore A silicone gaskets subjected to post­cooling treatment at 200°C C. Acrylic liquid paint finish with high resistance to atmospheric agents and UV rays; baking at 150°C. The optical assembly is closed with sodium-calcium tempered transparent clear semi-acid finished glass with antislip properties (in compliance with R12 class according to DIN 51130), 4mm thickness, fixed with silicone. Alluminium outer casing for installation with technopolymer caps to be ordered separately Ready for through wiring by means of four PG11 nickel­plated brass cable clamps suitable for 6.5 - 11mm cables contained in two thermoplastic boxs fixed to the optical assembly. All external screws are made of stainless steel A2.

  • Led lamp recessed
  • RGB change color system
  • DALI control system not included
  • Anticorrosive surface treatment
  • Power supply not included
Product Details
100% original product by :

2 Items

Data sheet

Barcode:
8025550190485
Reference
3.BA73.715.0
Input voltage
100-240 V
Depth in mm
117
Width in mm
101
Length in mm
719
Degree of protection
IP67
Material
Aluminum
Average hours duration
50000
Adjustable power
with DALI system
Watt power
18 W
Product Color
GRAY COLOR
Change colors
RGB (RED-GREEN-BLUE)
Weight in Kg
3,47
Carriageable
Yes
Mounting
Recessed
USA JAP compatible
Compatible
